Formula symbolsValueUnitDescription
Material
EN 10270-1
-
Type of material
Spring ends
Closed and ground
-
Spring ends
F1
N
prestressed spring force
L1
mm
Prestressed spring length
s1
mm
Prestressed spring deflection
F2
N
Loaded spring force
L2
mm
Loaded spring length
s2
mm
Loaded spring deflection
d
1.2
mm
Wire diameter
Di
mm
Inner coil diameter
D
9.8
mm
Mean coil diameter
De
11
mm
Outer coil diameter
Dd
8
mm
maximum diameter of mandrel
Dh
11.8
mm
minimum diameter of bush
L0
19.2
mm
unstressed spring length
Lk
mm
buckling length
Fn
75.413
N
maximum force in static use
Ln
7.44
mm
Minimum length in static use
sn
11.76
mm
Maximum spring deflection in static use
Fndyn
61.242
N
maximum force in dynamic use
Lndyn
9.65
mm
Minimum length in dynamic use
shdyn
3.7
mm
Maximum stroke in dynamic use
S
5.143
mm
pitch of spring
n
3.5
pc.
number of active coils
nt
pc.
total number of coils
R
6.413
N/mm
Spring rate
Weight
1.5138
g
weight of one spring
Fntol
4.49
N
(+/-) tolerance of maximum force in static use
Fndtol
4.45
N
(+/-) tolerance of maximum dynamic force
Detol
0.3
mm
(+/-) tolerances of outer coil diameter
L0tol
0.52
mm
(+/-) tolerance of unstressed spring length
Price group
E
-
price group
F1tol
N
(+/-) tolerance of prestressed spring force
F2tol
N
(+/-) tolerance of loaded spring force
